SP-50e

The SP-50e is an entry-level BioLogic potentiostat built around a simple, compact chassis. It is a fixed configuration instrument suited to general electrochemistry and corrosion applications.

Key specifications

Control voltage
±10 V
Voltage resolution
5 µV on 200 mV range
Compliance
±10 V
Current ranges
±1 A to ±10 µA (6 ranges)
Maximum current
±1 A
Current resolution
0.760 nA
Best acquisition time
20 µs with EC-Lab Express
