SP-150e
The SP-150e is a research grade BioLogic potentiostat built on a modular chassis, so the configuration can grow with your projects. Options include electrochemical impedance spectroscopy up to 1 MHz and external boosters for high current work. As standard, control voltage and compliance are ±10 V, adjustable anywhere between -20 V and +20 V, and the FlexP0060 or FlexP0160 options extend this to 60 V. Six current ranges cover ±1 A to ±10 µA , resolved to 0.004 % of the active range (760 pA minimum). With four FlexP0012 units in parallel, current can reach 800 A. The impedance range spans 1 MHz down to 10 µHz, and EC-Lab Express offers a 20 µs best acquisition time. That flexibility makes it a strong fit for battery materials, electrocatalysis, hydrogen and fuel cell research, sensors and corrosion studies across Australian universities and CSIRO-style applied labs. If the SP-150e sounds right for your group, ask ProDigitek for pricing or the full brochure.
Key specifications
Control voltage | ±10 V adjustable between[-20; to +20] V (standard); up to 60 V with FlexP0060/FlexP0160 |
Voltage resolution | 5 µV on 200 mV range |
Compliance | ±10 V adjustable between [-20; to +20] V (standard) |
Current ranges | ±1 A to ±10 µA (6 ranges) |
Maximum current | ±1 A; up to 800 A with four FlexP0012 |
Current resolution | 0.004 % of the range (min 760 pA) |
Frequency range | 1 MHz down to 10 µHz |
Best acquisition time | 20 µs with EC-Lab Express |
